PE-Xc Features tube
Product introduction
Modification of HDPE by physical method, the formation of cross-linked polyethylene and three-dimensional network structure.In the electron beam irradiation source intensity under certain circumstances, for a certain limit complete modification.Because the method does not need physical crosslinking, and peroxide initiator, catalyst, grafting agent and other substances, pure environmental protection, no pollution to water and other fluids, crosslinking content uniformity
Product features
Because the primary tube surface added anti UV coating, in addition to have all the advantages of PE-Xc color tube, but also improve the anti-aging properties of pipe products, stable performance, excellent physical and mechanical properties
The scope of application
1、floor heating system
2、with the solar energy pipe, radiator connection, drinking water transportation construction
Specification of pipe
| nominal outside diameter | Tube series | |
| S5 | S4 | |
| The nominal wall thickness (mm) | ||
| Sixteen | Two | Two |
| Twenty | Two | Two point three |
| Twenty-five | Two point three | Two point eight |
| Thirty-two | Two point nine | Three point six |
Specification
Coil, other specifications can be produced according to customer requirements and supply.
Packaging specifications
Dn16 360 DN20 300 m / M / volume / volume volume DN25 150 meters
Jilin Meigao Piping System Co., Ltd. originated from the Changchun Institute of Applied Chemistry, Chinese Academy of Sciences. It is a high-tech enterprise integrating R&D, production and sales of pipeline products and accessories. The company mainly produces electron beam irradiation cross-linked PE-Xc Pipes, heat-resistant polyethylene PE-RT pipes, PP-R pipes, pipe fittings, complete specifications.
